Type T Thermocouple Extension Wire Essential For Temperature Control In Laboratories And Industrial Processes

Cu-CuNi, Type T thermocouple extension wire, is recognized for its accuracy and stability in temperature measurement, particularly in low to moderate temperature ranges. Composed of a copper (Cu) positive leg and a copper-nickel (CuNi) negative leg, Type T thermocouples are designed for temperatures between -200°C and 350°C. They offer high sensitivity, approximately 43 µV/°C, and are known for their repeatability and resistance to oxidation in moist conditions. Type T thermocouples are widely used in cryogenic applications, laboratory settings, food processing for temperature control during cooking or freezing, and various industrial processes where precise temperature monitoring is essential. Their versatility and compatibility with standard measurement equipment make them a popular choice for applications requiring reliable temperature data in moderate temperature environments.

Color codes of thermocouple ( T type )

Type T thermocouple has good resistance to oxidation, high EMF output, with good temperature accuracy, sensitivity and stability. In the temperature range -200~0 ℃ , it has better property, the year stability is less than ±3μV.

Thermocouple temperature range and tolerance

Compensating wire reciprocating resistance:

Some Key Features Cu-CuNi (Type T) Constantan Thermocouple Wire include:

• Composition: Type T thermocouples consist of a positive leg made of pure copper (Cu) and a negative leg made of Constantan (CuNi), which is an alloy of approximately 55% copper and 45% nickel .
• Temperature Range: The operational temperature range for Type T thermocouples is from -200°C to +350°C . They are best suited for low to moderate temperature environments and are not advisable for use beyond this range due to the oxidation susceptibility of copper .
• Accuracy: Type T thermocouples have a high level of accuracy, with a sensitivity of about 43 µV/°C. They offer excellent repeatability between –200°C to 200°C .
• Advantages: Type T thermocouples are known for their high accuracy, stability, robustness, and resistance to oxidation. They perform well in the presence of moisture without oxidizing and are well-suited to oxidizing atmospheres .
• Insulation Material: MgO insulation is commonly used in Type T thermocouples due to its desirable characteristics such as fast response, compact size, broad temperature range, formability, weldability, durability, accuracy, and resistance to thermal shock and vibration .

In summary, Cu-CuNi (Type T) thermocouple extension wire is a reliable choice for temperature measurement in a variety of applications where low to moderate temperatures are involved.

Applications:

• Cryogenics: Type T thermocouples are reliable for ultra-low temperature measurements, making them ideal for cryogenic applications.
• Laboratory Environments: They are commonly found in laboratory settings for controlled experimental setups requiring precise temperature readings.
• Food Processing: Type T thermocouples are used for accurate temperature control during cooking or freezing processes in the food industry.
• Industrial and Commercial Temperature Sensing: These thermocouples play a pivotal role in industries such as power generation, oil/gas, pharmaceutical, biotech, cement, paper & pulp, and more, where precise temperature measurement is crucial.
• Domestic Appliances: Type T thermocouples are also used in everyday appliances like stoves, furnaces, and toasters for temperature sensing.
• Moist Environments: They perform well in the presence of moisture without oxidizing, making them suitable for use in moist environments.
• Oxidizing Atmospheres: Type T is well suited to oxidizing atmospheres, which adds to its versatility in industrial applications.

The Type T thermocouple extension wire's versatility, combined with its high accuracy and stability, makes it a popular choice for a range of temperature measurement applications.

Company Overview:

Jiangyin Chengxin Alloy Material Co., Ltd has more than 20 years of experience as the lead.ing alloy wire manufacturer in China. We offer a wide range of services from fine wire drawing toresistance wire manufacturing. Since the beginning, our specialty has been the quality and preci.sion of our products. We have the tightest tolerances and deliver within a few days to a fewweeks. As a result, we have become the leading alloy wire supplier in the industry.

Senphus Subsidiaries:

• Jiangyin Chengxin Alloy Material Co., Ltd.
• Jiangyin Senphus Electrical Materials Co., Ltd.
• Jiangsu Xiangcheng Supply Chain Management Co., Ltd.

Jiangyin Chengxin Alloy Material Co., Ltd.: With nearly 20 years of experience, Jiangyin Chengxin is a leading alloy wire manufacturer in China. We offer a wide range of services, from fine wire drawing to resistance wire manufacturing. Our specialty lies in the quality and precision of our products, achieving the tightest tolerances and delivering orders within days to weeks. As a result, we have established ourselves as the premier supplier of alloy wire in the industry.

Our product range includes:

• Copper-nickel alloys (CuNi1-CuNi44)
• Karma (Nikrothal L/Evanohm/Alloy 800)
• Manganin and Constantan
• Nickel-chromium alloys
• Thermocouple alloys (Type K, N, E, T, J)
• Thermocouple extension wire
• PTC thermistor resistance alloy
• Pure nickel wire and Monel alloy

These alloys are available in various forms, including wire, ribbon, stranded, and enamelled. Major applications include seat heating, underfloor heating, military projects, aerospace, household appliances, heating wire, mechanical and electrical plants, and temperature instruments. Our manufacturing processes are ISO 9001:2015 certified, and we specialize in fine and ultra-fine wire drawing, offering wire diameters from 0.025 mm (0.001") to 13 mm (0.51") in small batches, medium volumes, and mass production. We maintain a comprehensive quality inspection system, including in-house chemical analysis, chromatographic analysis, metallurgical analysis, pinhole tests, wire construction tests, and tension tests to ensure the highest quality standards.

Senphus Electrical Material Co., Ltd.: Founded in 2003, Senphus Electrical Material Co., Ltd. integrates research, manufacturing, and sales of electric heating alloys, heating cables, heating wires, and heating products. Leveraging over a decade of technical expertise in heating alloy wire, we have adopted advanced heating cable technology and machinery, successfully developing heating cables, temperature controllers, and temperature control systems suitable for building heating, pipe insulation, outdoor snow melting, wind power blade production, car seat heating, and healthcare applications.

The company is recognized as a high-tech enterprise in Jiangsu Province and a small giant enterprise in Jiangyin City, specializing in innovative technologies. We operate the "Wuxi Heating Cable Engineering Technology Research Center" and collaborate with experts from renowned domestic universities. Our portfolio includes 5 invention patents and over 30 utility model patents, showcasing our strong research and development capabilities.

With an annual output exceeding 1,000 tons of thermal alloy wire and an output value of approximately 105 million yuan, our products are well-received in markets such as the UK, Italy, Canada, Peru, and Spain. Our heating cables generate an annual output value of over 80 million yuan, with exports to Germany, Japan, the United States, Malaysia, Denmark, Brazil, and other countries.

The company has successfully passed multiple quality management system certifications, including IATF 16949, ISO 9001, ISO 14001 (Environmental Management System), and ISO 45001 (Occupational Health and Safety Management System). Our heating cables and related products have also obtained test reports from the Shanghai Cable Research Institute Test Center and received certifications such as UL (United States), VDE (Germany), CE (European Union), and RoHS.

Commitment to Quality: We adhere to the business commitment of "Reputation First, Quality First, Customer First" and uphold the quality policy of "Integrity-Based, Quality-Oriented, Excellent Service." We are dedicated to providing accurate products and professional services, and we look forward to collaborating sincerely with you to achieve mutual success.
